The new impervious fiber masonry furnace is used to avoid the cracking and falling off of the brick lining, save more than 20% of energy during heat treatment and reduce the equipment installation power by 15%.
The new impervious fiber masonry furnace is used to avoid the cracking and falling off of the brick lining, save more than 20% of energy during heat treatment and reduce the equipment installation power by 15%.
Electrothermal radiant tube is powered by a low voltage equipotential, increasing the service life of the radiant tube and the safe use of power for heating.
The quenching fluid tank is equipped with a variable frequency mixing system, and equipped with an air-cooled tubular heat exchanger. It is safe and secure.
The mechanical transmission adopts a geared motor, and the push-pull zipper is controlled by a digital encoder, and the action and positioning are accurate and reliable.
Complete safety and alarm system
The human-machine touch interface works in three modes: automatic, manual, and debugging, It can perform functions such as process editing, device operation, health monitoring, and reporting.
Carbon potential, temperature and operating procedures can be controlled by computer networking and can be recorded, stored, analyzed, etc. Off-line simulation and online dynamic control can be realized by computer expert system.
It can realize fully automatic joint control and group control of all equipment in the production line.
| Type | Work zone size (L×W×H) (mm) | Heating capacity (kg/h) | Maximum single load (kg) | Nominal temperature (°C) | Heating power (kW) | ||
| Multifunctional furnace | Tempering furnace | Multifunctional furnace | Tempering furnace | ||||
| RM-110/60/65-TL | 1100×600×650 | 350 | 600 | 950/1100 | 450/700 | 97/105 | 36/45 |
| RM-110/75/65-TL | 1300×750×600 | 350 | 800 | 97/105 | 36/45 | ||
| RM-130/75/75-TL | 1300×750×750 | 550 | 1000 | 125/150 | 45/60 | ||
| RM-130/75/90-TL | 1300×750×900 | 550 | 1200 | 125/150 | 45/60 | ||
| RM-150/100/75-TL | 1500×1000×750 | 600 | 1500 | 150/170 | 60/80 | ||
| RM-150/100/90-TL | 1500×1000×900 | 700 | 2000 | 170/190 | 75/90 | ||
| RM-150/100/105-TL | 1500×1000×1050 | 800 | 2500 | 190/210 | 90/100 | ||
| RM-180/120/90-TL | 1800×1200×900 | 900 | 3000 | 210/230 | 100/120 | ||
| RM-180/120/105-TL | 1800×1200×1050 | 1000 | 3500 | 230/250 | 110/140 | ||
| RM-180/120/120-TL | 1800×1200×1200 | 1100 | 4000 | 250/270 | 130/160 | ||
